Circuit Watch Surge Suppression Straight Blade Receptacle, Industrial/Commercial Grade, Isolated Ground, 15A 125V, 2- Pole 3-Wire Grounding, 5-15R

By Bryant

Catalog ID: SP52IGOA

By Bryant
Catalog ID:  SP52IGOA
Circuit Watch Surge Suppression Straight Blade Receptacle, Industrial/Commercial Grade, Isolated Ground, 15A 125V, 2- Pole 3-Wire Grounding, 5-15R, Orange

  • Quiet operation with sound levels below NEMA standards

    • Commercial Specification Grade

    Contact Us
    Add to List

    More Options

    Where to Buy

    Product Details

    General

    ANFC Taps 2
    Application IG Duplex with Light and Alarm
    BNFC Taps 2
    Color Orange
    Construction Ventilated
    EU RoHS Indicator No
    Environmental Conditions Indoor Dry Unless Protected By Additional Means
    Indicator(s) Type LED and Audible Alarm
    Item Type Surge Protection Receptacles
    Material Composite
    Material - Mounting Hardware Mounting Screws
    Max Temperature Rise 150 Degrees Celsius
    Mounting Type Floor
    OEM Brand Name Hubbell Bryant
    Operating Temperature 32 Deg F to 140 Deg F (0 Deg C to 60 Deg C)
    Outlet Straight Blade
    Primary Voltage 208Δ
    Product Category Dry Type Distribution Transformer
    Response Time 5
    Secondary Voltage 480Y/277 V
    Series Specification Grade
    Style Isolated Ground
    Taps % Steps 2.5%
    Type Duplex Receptacle
    UL Insulation Class 220°C
    UPC 047503093177 781786139114
    Winding Material AL
    kVA 75

    Dimensions

    Dimensions 22.37 in x 28.15 in x 29.41 in
    Display Size Standard
    Height 29.41 in
    Length 22.37 in
    Weight 530 lb
    Width 28.15 in

    Electrical Ratings

    Amperage Rating 15 A
    Connectivity Terminal Screws
    Current / Amperage Rating 15 A
    Current Rating 15 A
    Efficiency 98.60%
    Frequency Rating 60 Hz
    Phase Single Phase
    Primary Voltage 208D V
    Voltage Rating 125 V
    Voltage Rating Description 125 V

    Certifications and Compliance

    CSA Standard C22.2 No. 47
    Dept of Energy Regulation Meets or exceed U.S. DOE 10 CFR Part 431
    Nema Rating 5-15R NEMA 3R
    UL Standard UL 1561

    Logistics

    Carton Quantity 10 1
