Locking Devices, Industrial, Flush Receptacle, 30A 125V, 2-Pole 3-Wire Grounding, L5-30R, Screw Terminal, Black

By Bryant

Catalog ID: 70530FR

By Bryant
Catalog ID:  70530FR
Locking Devices, Industrial, Flush Receptacle, 30A 125V, 2-Pole 3-Wire Grounding, L5-30R, Screw Terminal, Black
  • Combination back and side wiring terminals accept #14 through #8 AWG solid or stranded conductors
  • Heavy duty mounting straps are nickel-plated to resist corrosion, wide width design assures secure assembly
  • NEMA rating and configuration are molded into face for easy identification
  • One-piece, rivetless copper-alloy contact design reduces heat buildup and provides secure blade retention

Standard Product

Contact Us
Add to List

More Options

Where to Buy

Product Details

General

Application Extra Heavy Duty Industrial Specification Grade
Environmental Conditions Indoor Dry Unless Protected By Additional Means
Item Type 30A Single Nylon Receptacle
Material - Mounting Hardware Screw Mounting
Number Of Poles 2-Pole
OEM Brand Name Hubbell Bryant
Series Replacement Part
Type Locking Receptacle
UPC 781786688735

Dimensions

Dimensions 3.28 in x 1.70 in x 1.24 in
Display Size Standard Sized Product
Height 1.24 in
Length 3.28 in
Width 1.70 in

Electrical Ratings

Amperage Rating 30 A
Connectivity Terminal Screws
Current Rating 30 A
Phase Single Phase
Voltage Rating 125 V
Voltage Rating Description 125V

Conductor Related

Number Of Wires 3-Wire
Wire Size #14 AWG to #8 AWG

Logistics

Carton Quantity 10
