LED Outdoor Commercial Floodlight - PMOFL

By Progress Lighting

Collection Name:  Multifamily/Commercial

Catalog ID: PMOFL-3-LS-CS-BZ

By Progress Lighting
Collection Name:  Multifamily/Commercial
Catalog ID:  PMOFL-3-LS-CS-BZ
The PMOFL Series offers a 52W LED floodlight made of rugged die-cast aluminum housing and a heat-resistant polycarbonate lens. It is intended for lighting applications such as safety/security, facade, area, or signs. The PMOFL can also be used for flag lighting, large sign, and statuary accent.
  • Rugged die-cast aluminum housing
  • Dark Bronze powder coat finish with polycarbonate lens
  • Available in 52W (6600 lumen) versions
  • Wide flood NEMA 7x7 distribution for general purpose flood and facade lighting
  • Ideal for multi-family, hospitality, and commercial applications
  • CCT field selectable feature offers 3500K, 4000K and 5000K options
  • Universal input voltage 120-277V, 50/60Hz
  • 0-10Vdc dimming standard
  • 50,000 hour LEDs for reduced maintenance
  • cULus listed for wet locations
  • Max ambient temperature rating 50°C
  • IP65 rated
Add to List

Buy from a Partner

Buy Now

More Options

Where to Buy

Product Details

General

Can be mounted up or down Yes
Color Bronze
Color Generic Brown
Color Rendering Index (CRI) 80 CRI
Color Temperature
  • 3000 K
  • 4000 K
  • 5000 K
Construction Material - Main Aluminum
Convertible fixture includes both mounts No
Dimming Range 0-10V
Dusk to Dawn No
Finish Name Dark Bronze
Finish Type Powder Coat
Fire Resistance No
Glass Clear
Lamp Included Yes
Lamp Type LED
Lamp Type Basic Solid State
Light Distribution Ambient
Mount location Wall
Mounting Type Wall
New Products Yes
Number of Lamps 1
Number of Lamps Total 1
Operating Temperature 50 °C
Post top fits standard No
Power Source Hardwired
Power Source Required? Yes
Quick Install canopy No
Quick Link connector No
Room Type
  • Outdoor
  • Landscape
  • Roadway
  • Security
  • Work Areas
Size Type Medium
Socket Base Type - Main Integrated
Socket type material LED
Starting Temperature - Minimum -40 °C
Sub Brand Progress LED
UPC 785247256655
Warranty Length 5-year Limited Warranty

Dimensions

Dimensions 8.7 in x 1.9 in x 9 in
Height 9 in
Length 8.7 in
Note Weight of fixture exceeds NEC limits No
Weight 4.7 lb
Width 1.9 in
Width Diameter Descriptor W.

Electrical Ratings

Current Rating
  • 0.26 A
  • 0.11 A
Frequency Rating 50/60 Hz
Lamp Wattage 52 W
Voltage Rating Universal 120-277 VAC

Conductor Related

Wire Length 6 in

Certifications and Compliance

Americans with Disabilities Act No
Certified Listed cULus
Certified Listed Location Wet Location Listed
DarkSky No
ENERGY STAR Certified No
Energy Efficient Yes
Industry Standard(s) FCC Part 15, Class A
JA8 No
Other Heavy Metal Content Indicator No
TM-21 50000
Title 24 No

Resource Links

Instruction Sheet Number 93165971

Resources and Downloads

Photometry (1)

Product Name Color Temp CRI Lumens Lm/W Watts Dist. Type Resources
PROG_IES-PMOFL-3_testlabreports
