6" Black Recessed Step Baffle Trim for 6" Housing (P806N series)

By Progress Lighting

Collection Name:  6" Recessed Trim

Catalog ID: P806000-031

By Progress Lighting
$22.55 USD
Collection Name:  6" Recessed Trim
Catalog ID:  P806000-031
The 6 in. Step Baffle Trim finished in Black offers one of the most popular recessed downlighting solutions. The single-piece aluminum construction eliminates light leaks around the flange and allows it to cover irregular ceiling openings. The surface baffles on the reflector offer a classic look and break-up the lamp reflection producing a more comfortable light. The socket mounts to the trim for optimum performance and consistent lamp position. The integrated torsion springs force trim to fit snugly against the ceiling, providing a secure trim installation and minimizing air leak. UL-CUL damp location rating makes this trim ideal for use in a variety of room settings in conjunction with 6 in. new construction or remodel recessed housing.
  • Durable, single-piece aluminum construction
  • Trim features single-piece construction that eliminates light leaks around the flange and allows it to cover irregular ceiling openings.
  • Easy installation featuring integrated friction springs forces the trim to fit snugly against the ceiling, providing a secure trim installation and minimizing air leak.
  • A crisp black finish and 6 in. aperture design makes this trim ideal for various downlighting solutions
  • Step surface baffle design break-ups the lamp reflection producing a more comfortable light
  • Measures 7.28125 in. D x 4.875 in. H
  • Uses 1 PAR38 light source (sold separately) 90-watt maximum
  • Use in conjunction with 6 in. new construction or remodel recessed housing
  • cULus damp location rating makes this trim ideal for use in a variety of room settings where water may be present
  • Warranty: Our 1-Year Limited Warranty guarantees your complete satisfaction with your purchase and includes professional after-sales customer service support
Add to List

Buy from a Partner

Buy Now

More Options

Where to Buy

Product Details

General

Aperture 5.96 in
Can be mounted up or down No
Color Black
Color Generic Black
Construction Material - Main Aluminum
Construction Material -Secondary Steel
Construction Material -Secondary part mounting bracket
Convertible fixture includes both mounts No
Dusk to Dawn No
Finish Name Black
Finish Type Powder Coat
Fire Resistance No
Lamp Included No
Lamp Shape PAR38
Lamp Type PAR38
Lamp Type Basic Incandescent
Lifestyle
  • Utilitarian
  • Traditional
  • Modern
  • Transitional
Light Distribution Down
Mount location ceiling in recessed housing
Mounting Type Recessed
Mounting for outlet box included N/A
New Products Yes
Number of Lamps 1
Number of Lamps Total 1
Photocell No
Post top fits standard No
Power Source Hardwired
Power Source Required? Yes
Quick Install canopy No
Quick Link connector No
Room Type
  • Bathroom
  • Bedroom
  • Bonus Room
  • Closets
  • Garage
  • Great Room
  • Kitchen
  • Living Room
  • Laundry
  • Utility
Socket Base Type - Main E26
UPC 785247251728
Warranty Length 1-year Limited Warranty

Dimensions

Dimensions 7.28125 in x 7.28125 in x 4.875 in
Height 4.875 in
Length 7.28125 in
Note Weight of fixture exceeds NEC limits No
Weight 0.25 lb
Width 7.28125 in
Width Diameter Descriptor dia.

Electrical Ratings

Lamp Wattage 90 W
Voltage Rating 120 VAC

Certifications and Compliance

Certified Listed cULus
Certified Listed Location Damp Location Listed
DarkSky No
ENERGY STAR Certified No
Energy Efficient Yes
JA8 No
Other Heavy Metal Content Indicator No
Title 20 N/A
Title 22 No
Title 24 No

Resource Links

Instruction Sheet Number 93158474
